Theseย examples (PDF) demonstrate the use of sensors in LabVIEW.
Graphing sensor values
- This program takes sensor values and graphs them on the front panel.
Line follower
- This program is provided in the “Behaviors” section of LabVIEW 2010. It can be very useful in more advanced projects, such as creating an NXT Trolley (a vehicle that follows a line, and stops with touch or sound.)
Multiple inputs and outputs
- This example demonstrates how to use multiple sensors and motors to control a vehicle. The while loops and case structures control the movement of the car. The purpose of the nested while loops is to permit holding down the buttons.
Use Sensor Values
- In this example, the NXT uses the values of the light and ultrasonic sensors to power the motor.
